10W/20W模拟无线图像发射模块（VTX）
10W/20W Analog Video Transmitter （VTX）
目录/ Table of Contents
1. 免责声明/ Disclaimer
2. 产品概述/ Product Overview
3. 核心特性/ Key Features
4. 物理尺寸/ Dimensions
5. 电气规格参数/ Electrical Specifications
6. 按键与LED 指示灯操作说明 / Button & LED Indication Operation
7. 三频段信道频点对照表/ Frequency Channel Table of Three Bands
8. 硬件接口说明/ Hardware Interface Description
9. 功率档位使用建议/ Power Level Application Guide
10. 安全使用注意事项/ Safety & Usage Precautions
11. 无线电合规声明/ Radio Regulatory Compliance Statement
1 免责声明 / Disclaimer
· 本手册仅用于产品操作指引，产品参数、外观若有升级优化，恕不另行通知；This manual is for operation guidance only. Product specifications and appearance are subject to upgrade without prior notice.
· 因违规操作、私自拆机、无天线发射、超压供电造成的设备损坏，不在保修范围内；Damage caused by improper operation, unauthorized disassembly, transmission without antenna or overvoltage power supply shall not be covered by warranty.
· 用户使用本设备需严格遵守当地无线电管理法律法规，非法频段使用后果由使用者自行承担。Users must comply with local radio management regulations. The user shall bear all liabilities arising from illegal frequency operation.
2 产品概述 / Product Overview
本产品为大功率FM 模拟无线图像发射模块（VTX），支持 PAL/NTSC 标准模拟 CVBS 视频输入，适配无人机、车载监控、应急巡检等专业无线图传场景。 This product is a high-power FM analog wireless video transmitter (VTX), compatible with PAL/NTSC analog CVBS video input, widely applied to UAV, vehicle monitoring, emergency inspection and other professional wireless video transmission scenarios.
模块支持DC 10–33V 宽电压供电，覆盖 1300–1500MHz、3200–3600MHz、4500-4700MHz、4990-5200MHz、5700–5900MHz 多个工作频段可选择定制；每个频段内置8 组可选工作频点 CH1–CH8，可通过机身按键手动切换频段与信道。设备采用标准 SMA 可拆卸射频天线接口，搭载 10W/20W 两档可调射频发射功率，远距离传输稳定性强。 The module supports wide DC 10–33V power input and operates in five frequency bands: 1300–1500 MHz, 3200–3600 MHz 4500-4700MHz、4990-5200MHz and 5700–5900 MHz customizable. Each band contains 8 selectable channels (CH1–CH8), which can be manually switched via onboard buttons. Equipped with detachable SMA RF antenna connector and dual adjustable RF output power (10W / 20W), it delivers stable long-range video transmission.
3 核心特性 / Key Features
l 供电：DC 10–33V 宽电压输入，适配各类机载锂电池、车载直流电源
Wide voltage input: DC 10–33 V, compatible with UAV lithium batteries and vehicle DC power supply
l 五频段工作：1300–1500MHz / 3200–3600MHz /4500-4700MHz、4990-5200MHz、 5700–5900MHz，每频段 8 信道 CH1~CH8
Five operating bands: 1300–1500MHz / 3200–3600MHz /4500-4700MHz/4990-5200MHz/ 5700–5900MHz, 8 channels (CH1~CH8) per band
l 双按键控制：CH 信道切换键、PW 功率切换键，搭配 LED 数码管状态显示
Dual control buttons: CH channel button, PW power button with digital LED status display
l 射频接口：标准SMA-K 可拆卸天线接口，50Ω 阻抗匹配
RF port: Detachable SMA-K antenna connector, 50Ω impedance matching
l 发射功率两档可调：10W（中远距调试）、20W（远距离视距传输）
Dual adjustable transmit power: 10W (Mid-range debugging), 20W (long-range line-of-sight transmission)
l 视频制式：自动兼容PAL / NTSC 复合模拟 CVBS 信号
Auto compatible with PAL / NTSC analog CVBS video signal
l 金属铝合金壳体，散热结构优化，长时间高功率工作不易过热
Aluminum alloy housing with optimized heat dissipation for continuous high-power operation
l 上电自动记忆关机前频段、信道、功率档位参数
Auto save last band, channel and power settings after power cycle
4 物理尺寸 / Dimensions
· 整机外形尺寸： 87 × 39 × 19 mm Overall dimension: 87 × 39 × 19 mm
· 安装固定孔距： 30.5 × 30.5 mm Mounting hole spacing: 30.5 × 30.5 mm
· 重量：80克 Weight: 80g
5 电气规格参数 / Electrical Specifications
参数项目Item | 参数规格Specification |
直流供电范围DC Input | DC 10 ~ 33 V |
射频接口RF Connector | SMA-K 50Ω |
调制方式Modulation | FM 模拟调频 FM Analog |
视频输入Video Input | CVBS，PAL / NTSC 自动识别 CVBS, PAL/NTSC auto detection |
工作频段Frequency Bands | 1300–1500MHz / 3200–3600MHz /4500-4700MHz/4990-5200MHz/ 5700–5900MHz |
单频段信道数量Channels per Band | 8 路（CH1~CH8） |
射频输出功率RF Output Power | 10W / 20W 两档可调 Dual levels |
工作温度Operating Temp | -20℃ ~ +65℃ |
存储温度Storage Temp | -30℃ ~ +75℃ |
相对湿度Humidity | 10% ~ 90%，无凝露 10%~90% non-condensing |
6 按键与 LED 指示灯操作说明 / Button & LED Indication Operation
设备配备两颗独立功能按键：CH 键（信道 / 频段切换）、PW 键（功率档位切换），LED 数码管实时显示当前状态，3 秒无操作自动锁定参数。
The device is equipped with two independent buttons: CH Button (Channel/Band Switch) and PW Button (Power Level Switch). Digital LED displays real-time status, and settings auto-lock after 3 seconds of inactivity.
6.1 CH 信道 / 频段切换键 CH Button
长按按键1 秒：进入频段切换模式，短按循环切换
Hold for 1s: Enter band switching mode; short press to cycle bands
· 短按按键单次：当前频段内循环切换CH1~CH8 频点
Single short press: Cycle CH1~CH8 within current band
· LED 显示：数码管直接展示当前信道编号CH1~CH8
LED Display: Digital tube shows active channel number CH1~CH8
· 静置3 秒无按键操作，系统自动保存并锁定当前频段与信道
Auto save & lock settings after 3s idle time
6.2 PW 功率档位切换键 PW Button
· 长按按键1 秒： 进入功率设置模式Hold for 1s: Enter power adjustment mode
· 短按按键单次： 循环切换10W 低档 / 20W 高档 Single short press: Toggle between 10W low power / 20W high power
· LED 功率状态指示表
功率档位Power Level | 输出功率Output Power | LED 闪烁提示 LED Indication | 适用场景Application |
低档Standard Mode | 10 W | 字符L 每 0.5 秒闪烁一次 "L" flashes every 0.5s | 室内调试、近距离短距离传输Indoor debugging, short-range transmission |
高档High Power Mode | 20 W | 字符H 每 0.5 秒闪烁一次 "H" flashes every 0.5s | 开阔视距远距离传输，最远15~30km Open line-of-sight long-range transmission (15–30km max) |
· 自动锁定： 静置3 秒自动锁定功率档位，断电记忆保存 Power setting auto-locked after 3s idle, saved after power off.
7 三频段信道频点对照表 / Frequency Channel Table
说明： 下表为设备出厂标准频点值，设备LED 显示数值与下表一一对应；用户通过 CH 键切换信道选择对应频率。
Note: The table shows factory default frequency values, consistent with LED display; switch channels via CH button to select target frequency.
7.1 1300–1500MHz 频段（1.3G 频段）
信道编号Channel | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
中心频率(MHz) Center Frequency | 1320 | 1340 | 1360 | 1380 | 1400 | 1420 | 1440 | 1460 |
7.2 3200–3600MHz 频段（3.3G 频段）
信道编号Channel | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
中心频率(MHz) Center Frequency | 3300 | 3320 | 3340 | 3360 | 3380 | 3400 | 3420 | 3440 |
7.3 4500–4675MHz 频段（4.5G 频段）
信道编号Channel | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
中心频率(MHz) Center Frequency | 4500 | 4525 | 4550 | 4575 | 4600 | 4625 | 4650 | 4675 |
7.4 4990–5200MHz 频段（4.9G 频段）
信道编号Channel | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
中心频率(MHz) Center Frequency | 4990 | 5020 | 5050 | 5080 | 5110 | 5140 | 5170 | 5200 |
7.5 5700–5900MHz 频段（5.8G频段）
信道编号Channel | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
中心频率(MHz) Center Frequency | 5705 | 5725 | 5745 | 5765 | 5785 | 5805 | 5825 | 5845 |
8 硬件接口说明 / Hardware Interface Description
电源输入接口/ Power Input Port
直流DC 10–33V 输入，严格区分正负极；建议搭配纹波小、电流余量充足的稳压电源，避免电压波动导致画面卡顿、功率不稳。 DC 10–33V input with positive/negative polarity distinction. Stable power supply with sufficient current margin is recommended to avoid picture lag or unstable RF power caused by voltage fluctuation.
视频输入接口/ Video Input Port
标准模拟CVBS 视频信号输入，自动兼容 PAL、NTSC 摄像头 / 航拍相机视频输出，支持同轴 AV 线连接。 Standard analog CVBS input, auto compatible with PAL/NTSC aerial camera, connected via coaxial AV cable.
SMA 射频天线接口 / SMA RF Antenna Port
50Ω 标准 SMA 母座，必须安装匹配天线后再接通电源；严禁空载上电发射射频信号。 50Ω standard SMA female connector. Always mount matched antenna before power on; RF transmission without antenna is strictly prohibited.
9 功率档位使用建议 / Power Level Application Guide
功率档位Power Level | 推荐使用场景Recommended Application |
10W 低档 | 室内调试、近距离试飞、多设备同场作业（减少干扰）、合规短距离场景Indoor debugging, short-distance test flight, multi-device co-working (reduce interference), legal short-range scenarios |
20W 高档 | 野外开阔无遮挡视距传输、长距离无人机巡检、车载远程监控（视距最大15–40km） Open unobstructed outdoor transmission, long-range UAV inspection, vehicle remote monitoring (max 15–40km line-of-sight) |
10 安全使用注意事项 / Safety & Usage Precautions
10.1 散热要求 / Cooling Requirement
设备高功率工作时发热量较大，安装位置必须保证空气流通，禁止封闭包裹、紧贴隔热材质；设备过热会自动触发热保护，降低发射功率甚至切断射频输出。The unit generates heavy heat under high-power operation. Ensure sufficient ventilation, avoid fully enclosed installation or contact with thermal insulation materials. Overheating will trigger thermal protection, reducing RF power or cutting off transmission.
10.2 电源规范 / Power Specification
供电电压必须稳定在DC10–33V 区间，接线时确认电源正负极，反接会直接烧毁内部电路；电池供电机型需预留充足放电电流。 Input voltage must stay within DC10–33V range. Confirm polarity before wiring; reverse connection will permanently damage internal circuits. Sufficient discharge current is required for battery-powered systems.
10.3 天线强制规范 / Antenna Mandatory Rule
禁止无天线通电发射！ 空载射频输出会瞬间击穿功放芯片，造成不可逆硬件损坏，此类损坏不在保修范围。Never power on without antenna connected. RF output without load will burn power amplifier instantly, irreversible hardware damage excluded from warranty.
10.4 设备防护 / Protection
避免雨水、粉尘、剧烈震动冲击；户外使用建议搭配防水外壳，长期闲置断开电源存放于干燥常温环境。Avoid rain, dust and violent vibration. Outdoor application requires waterproof housing; disconnect power and store in dry room temperature for long-term standby.
10.5 操作规范 / Operation Standard
仅使用本手册规定方式切换频段、信道、功率；禁止拆机、改装射频电路、更换非原厂功放配件。Adjust band, channel and power only per manual instructions. Unauthorized disassembly, RF circuit modification or non-original power amplifier replacement are forbidden.
11 无线电合规声明 / Radio Regulatory Compliance Statement
· 本设备射频发射功率、工作频段仅适用于符合当地无线电管理法规的授权应用场景；The RF transmit power and operating bands of this device shall only be used in authorized scenarios compliant with local radio regulatory laws.
· 商用、机载、车载作业前，用户需自行完成无线电设备备案、频段使用许可等相关手续；Before commercial, UAV or vehicle deployment, users shall complete radio equipment filing and frequency license procedures independently.
· 严禁在机场、军事管制区、涉密区域、人群密集城区违规使用大功率射频发射设备，违规使用将承担相应法律责任。High-power RF transmitters are prohibited from illegal operation near airports, military restricted zones, confidential areas and densely populated urban areas. Users shall bear all corresponding legal liabilities for violations.
